AC DC 96W 24V 4A UL Class 2 Power Adapter

The KSPOWER 24V 4A UL Class 2 Power Adapter is a 96W desktop AC/DC power supply designed for North American markets. Certified to UL 1310 Class 2 requirements, it features universal 100-240VAC input, stable 24VDC output, DOE Level VI efficiency, and comprehensive protection functions. Available with interchangeable IEC AC inlet or fixed AC cable, it is ideal for LED lighting, access control, industrial automation, medical devices and OEM equipment.

Need help choosing a model? Send your application requirements to our team for a recommended solution.

AC DC 96W 24V 4A UL Class 2 Power Adapter

Accelerate your North American project approvals while slashing installation costs. The KSPOWER 24V 4A (96W) UL1310 Power Supply is the definitive safety solution for professional low-voltage systems. Engineered to the strict UL 1310 Class 2 standard, this adapter inherently limits output energy to eliminate fire and shock hazards. For contractors and OEMs, this 24V 4A UL Class 2 power adapter means full NEC compliance and the ability to use simplified, cost-effective wiring methods without expensive conduits.

Technical Specifications

Item	Specification
Model	ZF120A-2404000 (24V 4A platform)
Output Voltage	24V DC
Output Current	4A
Output Power	96W
Class 2 Rating	UL Class 2 (max 100VA / 24V, inherently limited)
Input Voltage	100-240VAC (universal)
Input Frequency	50/60Hz
Efficiency	Level VI
No-Load Power	<0.21W
Protection	OVP / OCP / SCP / LPS (Limited Power Source)
Operating Temperature	-10 C to +40 C
Storage Temperature	-20 C to +85 C
Housing	PC flame-retardant plastic case (fully enclosed)
AC Inlet	IEC320-C8 (Class II) / IEC320-C6 / IEC320-C14 (Class I)
DC Connector	5.5×2.1mm male (or custom)
DC Cord	1.2m standard (or custom)
AC Plugs	US / EU / UK / AU / KR / CN (optional)
LED Indicator	Power on indicator (green)
Safety Certifications	UL cUL Class 2 / FCC / CE / PSE / CCC / KC / KCC / RCM / SAA / UKCA / RoHS
Warranty	3 Years

What is 24V 4A UL Class 2 Power Adapter?

UL 96W Class 2 Adapter is a safety classification defined by UL (Underwriters Laboratories) and the National Electrical Code (NEC) for power supplies with inherently limited energy output. Key characteristics:

Parameter	UL Class 2 Limit	This Adapter (24V 4A)
Output Voltage	Max 50V DC	24V DC
Output Power	Max 100VA	96VA (96W)
Output Current	Limited to safe value	4A (within limit)
Energy Limitation	Inherently limited (no external fuse needed downstream)	Yes – internal current/power limiting
Wiring Requirements	Reduced wiring methods per NEC	No secondary overcurrent protection required

Benefits of UL Class 2:

Eliminates need for secondary overcurrent protection (fuse/circuit breaker) downstream of the adapter
Reduces fire and shock hazard through inherent energy limitation
Simplifies wiring and lowers installation cost in LED lighting, security and IoT systems
Mandatory for many UL-listed luminaires, surveillance systems and connected devices in North America
Wiring can use Class 2 cables (e.g., CL2, CL2P, CL2R) with reduced conduit requirements

AC Input Connector Options

IEC Type	Protection Class	Grounding	Best For
IEC320-C8	Class II (double insulated)	No earth pin	Lightweight designs, portable equipment, consumer electronics, no ground needed
IEC320-C6 (cloverleaf)	Class I (with earth)	Earth pin	Industrial equipment, metal enclosures, equipment requiring ground connection
IEC320-C14	Class I (with earth)	Earth pin	Rackmount, higher power systems, permanent installations

INFO Select IEC type based on your equipment’s protection class and grounding requirements. C8 = Class II no ground; C6/C14 = Class I with ground.

Applications

Application	Typical Devices	Power Need	Why UL Class 2
LED Lighting	LED strips, LED luminaires, signage, display lighting	24V / 60-96W	NEC Class 2 wiring, reduced conduit, UL-listed fixtures
Security & CCTV	IP cameras, DVR/NVR, access control, alarm systems	24V / 48-96W	No secondary fuse needed, safe low-voltage wiring
Connected Home / IoT	Smart home hubs, sensors, gateways, home automation	24V / 24-96W	Inherently safe, reduced shock/fire risk
Telecom & Networking	Modems, switches, routers, communication modules	24V / up to 96W	Clean regulated power, global certifications
Industrial Controls	Small motors, actuators, controllers, sensors	24V / 48-96W	Class 2 limited energy, simplified wiring
Consumer Electronics	LCD monitors, audio equipment, set-top boxes	24V / 48-96W	Safe external power supply, UL listed
Medical Equipment (non-patient contact)	Diagnostic devices, equipment stands, carts	24V / up to 96W	Low voltage, limited energy, reduced hazard
3D Printers & Hobby	FDM printers, resin printers, DIY projects	24V / 60-96W	Stable regulated output, high current

OEM / ODM Customization

Electrical: output voltage / current / power within Class 2 limits
Connectors: DC 5.5×2.1mm, 5.5×2.5mm, USB-C, XLR, JST, Molex, aviation connectors, or custom
Cable: custom length, wire gauge, colors, and strain relief
AC inlet: IEC C6 / C8 / C14 per your grounding and protection class requirements
AC plugs: US / EU / UK / AU / KR / CN plugs for target markets
Branding: logo printing, nameplate design, product labels, user manuals
Packaging: brown box, white box, retail box, gift box, or customized cartons
Housing: custom color (black / white / custom), private mold design
Certification support: configuration per destination market requirements (UL, CE, FCC, etc.)
Private label / brand development for distributors and OEM customers

Q1. Why is 96W the limit for a 24 Volt Power Adapter?

A. Per the UL 1310 and NEC standards, a Class 2 power source must not exceed 100 volt-amperes (VA). For a 24V system, this calculates to roughly 4.0 Amps (96W). Our adapter provides the absolute maximum power possible while staying within this critical safety threshold.

Q2. Does using a 24V 4A Power Adapter really reduce my installation costs?

A. Yes. In many commercial and residential jurisdictions, the National Electrical Code (NEC) allow Class 2 wiring to be installed without the same heavy-duty conduit or fire-rated raceways required for standard Class 1 circuits. This can save you between 20% to 50% on labor and material costs for low-voltage wiring.

Q3. I see the factory is Zhenhuan but the brand is Keysun. Will this pass an audit?

A. Absolutely. Zhenhuan is our manufacturing base, and Keysun is our brand and certification entity. All UL files (e.g., E497389) link these two together. We provide all necessary technical documentation and authorization letters to ensure your procurement and inspection teams have 100% confidence in the traceability of the product.
